Запчасти Komatsu PC45-1 ГЕНЕРАТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC45-1 - ГЕНЕРАТОР ДВИГАТЕЛЬ
26
25
28
24
27
1
23
22
4
3
2
21
19
20
18
16
14
17
7
15
6
11
8
13
12
9
5
10

Артикул

Название

Примечание

Количество

1

YMR000026

GENERATOR

2

YMR000027

ROTOR

3

YMR000042

BEARING

4

YMR000028

STATOR

5

YMR000029

COVER, ASSY.

6

YMR000030

COVER, REAR

7

YMR000031

BRUSH ASSY., REGULATOR

8

YMR000032

FLEX HORN

9

YMR000033

GUIDE

10

YMR000034

DIODE ASSY.

11

YMR000035

CONDENSER

12

YMR000044

SCREW

13

YMR000045

SCREW

14

YMR000046

CABLE, ASSY.

15

YMR000036

COVER ASSY., FRONT

16

YMR000037

RETAINER

17

YMR000041

BEARING

18

YMR000043

KIT, SCREW

19

YMR000038

PULLEY

20

YMR000039

NUT ASSY., PULLEY

21

YMR000040

KIT, SCREW

22

YMR000502

SCREW

23

YMR000025

SPACER

24

YMR000425

NUT

25

YMR000521

ADJUSTER, BELT

26

YMR000391

BOLT

27

YMR000356

WASHER

28

YMR001089

NUT

Выбрано товаров: 28
