Запчасти Komatsu PC45-1 ТОПЛ. НАСОС ДВИГАТЕЛЬ

1

YMR001097

PUMP, ASSY.

4

YMR000545

CAMSHAFT ASSY.

5

YMR000207

BEARING

6

YMR000208

RETAINER

7

YMR000075

KEY

8

YMR000284

PLUNGER W/BARREL

11

YMR000209

PIN

12

YMR000350

RETAINER, SPRING

13

YMR000210

SEAT, NOZZLE SPRING

14

YMR000095

SPRING

15

YMR000211

TAPPET

22

YMR000213

LOCKING, TAPPET

23

YMR000214

O-RING

24

YMR000288

VALVE DELIVERY

27

YMR000215

SPRING

28

YMR000216

GUARD, DELIVERY VALVE

29

YMR000087

GASKET

30

YMR000088

O-RING

31

YMR000217

STOPPER

32

YMR000218

LOCKING (A)

33

YMR000219

LOCKING (B)

34

YMR000558

DEFLECTOR

35

YMR000221

CHECK BOLT

36

YMR000222

PLUG

37

YMR000223

KIT, SHIM

42

YMR000559

RACK

43

YMR000225

BUSHING

44

YMR000226

SPACER

45

YMR000227

RING, SNAP

46

YMR000228

PINION

47

YMR000074

SCREW

48

YMR000351

PINION

49

YMR000229

PLUG

50

YMR000230

O-RING

51

YMR000231

SPRING

52

YMR000232

KIT, SHIM

71

YMR000560

COVER

72

YMR000561

GASKET

73

YMR000562

COVER

74

YMR000563

GASKET

75

YMR000237

LOCKING, RACK

76

YMR000260

PLATE, CAUTION

77

YMR000238

SPACER T=3.25

78

YMR000239

SPACER T=1.5

79

YMR001016

SPRING WASHER

80

YMR000364

PEG

81

YMR000381

BEARING

82

YMR000387

O-RING

83

YMR000393

SCREW

84

YMR000394

SCREW

85

YMR000415

SCREW

86

YMR000428

NUT

87

YMR001017

WASHER

88

YMR000206

STUD

89

YMR000240

GASKET

90

YMR000480

PUMP, ASSY.

92

YMR000262

DIAPHRAGM

94

YMR000263

COVER

95

YMR000264

GASKET

96

YMR000265

BOLT

97

YMR000266

PLUG

98

YMR000268

SPRING

99

YMR000269

TAPPET

100

YMR000270

SPRING

101

YMR000271

PIN

102

YMR000272

LINK

103

YMR000273

SPRING

104

YMR000274

PIN

105

YMR000275

O-RING

106

YMR000187

FUEL INJECTION GEAR

107

YMR000429

NUT

108

YMR000358

WASHER
