Запчасти Komatsu PC45-1 МАРКИРОВКА (НАВЕС) МАРКИРОВКА

Схема запчастей Komatsu PC45-1 - МАРКИРОВКА (НАВЕС) МАРКИРОВКА
28
a
a
10
b
c
d
3
e
7
9
1
y
y
a
2
b
7
e
d
c
8
6
33
9
11
29
30
12
13
31
2
8
4
11
9
31
27
32
15
28
16
14
26
25
34
22
21
20
23
24
17
18
19
5

Артикул

Название

Примечание

Количество

\0

816214309

MARK PLATE KIT

\0

816214391

MARK PLATE KIT

1

PLATE FAI KOMATSU

1

PLATE KOMATSU

2

PLATE FAI KOMATSU

2

PLATE KOMATSU

3

PLATE

4

PLATE

5

PLATE, OPERATING, RAISING CAPACITY

\5

816214231

KIT, MARK PLATE

6

PLATE, SAFETY, KEEP OUT TURNING AREA

7

PLATE, SAFETY, DO NOT OPEN ENGINE HOOD

8

PLATE, READ MANUAL

9

PLATE, LUBRICATING POINT

10

PLATE, LIFTING POINT

11

PLATE, ANCHOR POINT

12

PLATE, SAFETY, FUEL

13

PLATE, CONTROLS LEVER, BOOM SWING, ATTACHMENT

14

PLATE, SAFETY, HYDRAULIC OIL LEVER

15

PLATE, OPERATING, CONTROL LOCK

16

PLATE, SAFETY, HYDRAULIC OIL

17

PLATE, SAFETY, HYDRAULIC OIL FILTER

18

PLATE, SAFETY, GREASE

19

PLATE, SAFETY, ELECTRIC SOCKET

20

PLATE, OPERATING, ATTACHMENT

21

PLATE, OPERATING SWING LOCK LEVER

22

PLATE, OPERATING, TRAVEL SPEED

23

PLATE, SAFETY, ENGINE OIL FILTER

24

PLATE, SAFETY, ENGINE AIR FILTER

25

PLATE, SAFETY FUEL FILTER

26

PLATE, SAFETY, RADIATOR CAP

27

PLATE, OPERATING, FUEL CONTROL

28

PLATE, OPERATING BLADE

29

PLATE, SAFETY, DO NOT STATION IN THE WORK AREA

30

PLATE, OPERATING, PPC VALVE (R.H.)

31

RING, SNAP

32

PLATE, OPERATING, PPC VALVE (L.H.)

33

816212855

PLATE, MARK, SOUND POWER LEVEL LWA 97

33

3F10B2642

PLATE, MARK, SOUND POWER LEVEL LWA 98

34

816212389

PLATE, MARK, SOUND PRESSURE LEVEL LPA 80

34

3F10B2641

PLATE, MARK, SOUND PRESSURE LEVEL LPA 81

Выбрано товаров: 41
