Запчасти Komatsu PC45-1 РЕГУЛЯТОР ДВИГАТЕЛЬ

1

YMR000214

O-RING

2

YMR001018

CASE, GOVERNOR

3

YMR000242

GASKET

4

YMR000243

COVER

5

YMR000244

GASKET

6

YMR000245

LINK L=30 (0)

7

YMR000246

LINK L=31 (1)

8

YMR000247

LINK L=30.5 (0.5)

9

YMR000248

WEIGHT ASSY., GOVERNOR

13

YMR000249

SLEEVE

14

YMR000486

SLEEVE

15

YMR000487

SLEEVE

16

YMR000122

SHAFT

19

YMR000250

SPACER

23

YMR000123

LEVER

24

YMR000251

BOLT, REVOL. LIMIT

25

YMR000252

BOLT, IDLE LIMIT

26

YMR000488

SCREW

27

YMR000253

SPACER

32

YMR000254

SHAFT

33

YMR000596

LINK ASSY., GOVERNOR

34

YMR000352

SHIM

51

YMR000256

SHIFTER

52

YMR000125

SPRING

53

YMR000278

LEVER, STOP

54

YMR000257

PIN

55

YMR000258

O-RING

56

YMR000259

SCREW

57

YMR000090

NUT

58

YMR000354

WASHER

59

YMR000359

RING, SNAP

60

YMR000360

RING, SNAP

61

YMR000361

WASHER

62

YMR000362

SPRING

63

YMR000598

PIN, SAFETY

64

YMR000380

PLUG

65

YMR000385

O-RING

66

YMR000393

SCREW

67

YMR000397

SCREW

68

YMR000425

NUT

69

YMR000430

NUT

70

YMR000431

NUT

71

YMR001022

WASHER

72

YMR001023

WASHER

73

YMR000852

WASHER

74

YMR000489

SPRING

75

YMR000427

CAP NUT

76

YMR001021

SCREW

77

YMR000126

SPRING

78

YMR000567

ANGLEICH ASSY.

82

YMR000858

NUT
