Запчасти Komatsu PC45-1 ГИДР. НАСОС. (/)(№-) ГИДРАВЛИКА

Схема запчастей Komatsu PC45-1 - ГИДР. НАСОС. (/)(№-) ГИДРАВЛИКА
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35

Артикул

Название

Примечание

Количество

|1

20T-60-72110

HYDRAULIC PUMP ASS'Y

|1

UC4100325081

HANGER ASS'Y

1

HANGER

2

BEARING

3

SHAFT

4

PIN

5

PIN

6

UC1300233008

O-RING

7

04065-05020

RING,SNAP

8

UC1100083551

SHIM

9

UC1100266251

COVER

10

UC1300245001

O-RING

11

01252-30616

BOLT

12

UC1100300205

COVER

13

UC1198273603

PLUG

14

07000-12011

O-RING

15

UC1180769084

ORIFICE

16

07000-11008

O-RING

17

UC1100280844

PLATE,CONTROL

18

UC1100266233

BEARING

19

UC1302180025

PIN

20

UC1300541006

O-RING

21

01252-31030

BOLT

22

01252-31040

BOLT

23

UC1100300892

SPRING

24

UC1100288792

SPRING

25

UC1100266196

SEAT

26

UC1100266178

SCREW,ADJUST

27

UC1100266187

SCREW,ADJUST

28

UC1303007141

BALL

29

UC1302094025

SCREW

30

UC1100264145

COVER

31

07000-02085

O-RING

32

UC1100220475

NUT

33

UC1303015555

NUT

34

UC1300073008

O-RING

35

01252-30825

BOLT

Выбрано товаров: 37
