Запчасти Komatsu PC45-1 ГИДР. НАСОС. (/)(№-) ГИДРАВЛИКА

|$0

20T-60-74410

HYDRAULIC PUMP ASS'Y

|$2

UC4100437414

COVER ASS'Y

1

COVER

2

UC1100393986

PLATE,CONTROL

3

PIN

4

01252-31230

BOLT

5

UC1303040074

O-RING

6

UC1800042641

O-RING

7

UC1701538797

PLUG

8

UC1100232432

ORIFICE

9

BEARING

10

UC1198273502

PLUG

11

07000-11008

O-RING

|$14

UC4100360819

CYLINDER ASS'Y

12

UC1100360692

CYLINDER

13

UC1100360509

PISTON

14

UC1100324412

PIN

15

UC1100360784

PIN

16

UC1198273704

PLUG

17

01252-30825

BOLT

18

UC1100329802

WASHER,SPRING

19

UC1300038005

O-RING

20

UC1300014009

O-RING

21

07000-12011

O-RING

|$25

UC4100411879

SPRING ASS'Y

22

UC1100327714

SEAT,SPRING

23

UC1100360519

SEAT,SPRING

24

UC1100356959

COVER

25

UC1100330307

SCREW,ADJUSTER

26

UC1100359692

SPRING

27

UC1100411882

SPRING

28

UC1301240007

O-RING

29

01252-30830

BOLT

30

UC1301987009

NUT

31

UC1704091869

SHIM, 0.3MM

31

UC1303036213

SHIM, 0.5MM

31

UC1100229436

SHIM, 1.0MM

31

UC1100229445

SHIM, 2.0MM
