Запчасти Komatsu PC40R-8 ОСНОВН. КОНСТРУКЦИЯ (ЭЛЕКТРОПРОВОДКА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC40R-8 - ОСНОВН. КОНСТРУКЦИЯ (ЭЛЕКТРОПРОВОДКА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
1
2
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19A
19A
19B
20
20
21
22
23
24
25
26
27
28
29
30
31
31
32
32
33
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52

Артикул

Название

Примечание

Количество

1

20T-06-81311

WIRING HARNESS

1

08020-00000

DIODE

2

20T-06-71560

FUSE BOX

3

20T-06-71571

PLATE, NAME

4

283-06-16190

FUSE, 10A

5

22W-06-13160

FUSE, 20A

6

201-06-61240

FUSE, 30A

7

04434-51910

CLIP

8

01010-81020

BOLT

9

01643-31032

WASHER

10

21W-06-21151

BRACKET

10

21W-06-21152

BRACKET,(FOR ONE TOUCH DECEL)

11

01010-80820

BOLT

12

20T-54-71550

BOLT

13

01643-30823

WASHER

14

04434-52511

CLIP

15

04434-52511

CLIP

16

01010-81020

BOLT

17

01643-31032

WASHER

18

20S-06-31130

STARTING SWITCH,STARTING

19

20T-54-85130

WIRING HARNESS,(FOR CAB)

19A

20T-910-8530

WIRING HARNESS,(FOR 1 ATTACHMENT AND PAT)

19B

04435-51910

CLIP,(FOR 1 ATTACHMENT AND PAT)

20

20T-06-81330

BRACKET

21

01010-81025

BOLT

22

01643-31032

WASHER

23

20T-06-71760

TIMER

24

01220-40620

SCREW

25

01641-20608

WASHER

26

01602-20619

WASHER,SPRING

27

20T-06-71320

BUZZER ASS'Y

28

01220-40616

SCREW

29

01602-20619

WASHER,SPRING

30

01641-20608

WASHER

31

20T-06-71770

SWITCH,P.P.C. LOCK

32

20T-06-71780

WIRING HARNESS

33

20U-43-21360

SCREW

34

01641-20508

WASHER

35

08034-20823

BAND

36

20T-06-71650

RELAY,SAFETY

37

08038-00519

CAP

38

01220-40616

SCREW

39

01602-20619

WASHER,SPRING

40

01641-20608

WASHER

41

20T-06-71750

RELAY ASS'Y,STOP

42

01220-40616

SCREW

43

01641-20608

WASHER

44

01602-20619

WASHER,SPRING

45

21X-06-12310

RELAY ASS'Y,P.P.C. LOCK

46

01220-40616

SCREW

47

01602-20619

WASHER,SPRING

48

01641-20608

WASHER

49

21X-06-12310

RELAY ASS'Y,(FOR 1 ATTACHMENT AND PAT)

50

01220-40616

SCREW,(FOR 1 ATTACHMENT AND PAT)

51

01602-20619

WASHER,SPRING

52

01641-20608

WASHER,(FOR 1 ATTACHMENT AND PAT)

Выбрано товаров: 56
