Запчасти Komatsu PC40R-8 КРЕПЛЕНИЕ ДВИГАТЕЛЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

20T-01-71212

BRACKET,REAR R.H.

2

01010-81030

BOLT

3

01643-31032

WASHER

4

20S-01-71331

CUSHION

5

01580-11008

NUT

6

01643-31032

WASHER

7

20T-01-71222

BRACKET,REAR L.H.

8

01010-81030

BOLT

9

01643-31032

WASHER

10

20S-01-71331

CUSHION

11

01580-11008

NUT

12

01643-31032

WASHER

13

20T-01-71270

BRACKET,FRONT R.H.

14

01010-81025

BOLT

15

01643-31032

WASHER

16

20S-01-71331

CUSHION

17

01580-11008

NUT

18

01643-31032

WASHER

19

20T-01-71280

BRACKET,FRONT L.H.

20

01010-81025

BOLT

21

01643-31032

WASHER

22

20S-01-71331

CUSHION

23

01580-11008

NUT

24

01643-31032

WASHER

25

08036-11014

CLIP

25

20T-43-77141

BRACKET

26

01010-80825

BOLT

27

01643-30823

WASHER

28

04434-51010

CLIP

29

01010-81020

BOLT

30

01643-31032

WASHER

31

20T-01-81410

BRACKET

32

08036-21014

CLIP

33

01010-80616

BOLT

34

01643-30623

WASHER

35

7861-92-3320

SENSOR,WATER TEMPERATURE

36

515-35-13930

CLIP

37

01010-80816

BOLT

38

01643-30823

WASHER
