Запчасти Komatsu PC40R-8 2-СЕКЦИОНН. СТРЕЛА (CROSS СОЕДИНИТЕЛЬН. ЗВЕНО ТИП) (1¤ 2-Я СТРЕЛА¤ РУКОЯТЬ ЛИНИЯ И ЛИНИЯ КОВША) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20T-70-01210

BOOM ASS'Y,(1ST BOOM)

1

1ST BOOM

2

20T-70-82530

BUSHING

3

07145-00065

SEAL,DUST

4

07020-00900

FITTING,GREASE

5

07049-01215

PLUG

|6

20T-70-01290

BOOM ASS'Y,(2ND BOOM)

6

2ND BOOM

7

20T-70-82540

BUSHING

8

07145-00055

SEAL,DUST

9

07020-00000

FITTING,GREASE

10

07049-01215

PLUG

11

07217-50712

ELBOW

12

07214-50710

CONNECTOR

13

20T-62-82310

TUBE

14

20T-62-82320

TUBE

15

20X-62-23160

CLAMP

16

01010-81020

BOLT

17

01643-31032

WASHER

18

20T-62-82181

PLATE

19

01010-81025

BOLT

20

01643-31032

WASHER

21

20T-62-82440

HOSE

22

20T-62-82360

HOSE

23

04434-52708

CLIP

24

07095-20420

CUSHION

25

04434-53211

CLIP

26

07095-20523

CUSHION

27

01010-81020

BOLT

28

01643-31032

WASHER

29

08034-30521

BAND

30

20T-62-82320

TUBE

31

20T-62-82370

HOSE

32

20T-62-82331

TUBE

33

201-62-21890

CLAMP

34

01010-81020

BOLT

35

01643-31032

WASHER

36

144-920-9480

CLAMP

37

01010-81020

BOLT

38

01643-31032

WASHER

39

20T-63-X2703

CYLINDER GROUP,BOOM

40

20T-70-71190

COVER

41

01010-81030

BOLT

42

01643-31032

WASHER

43

20T-70-71630

PAD

44

20T-70-71640

COLLAR

45

01010-80816

BOLT

46

01643-30823

WASHER

47

20T-63-X2414

CYLINDER GROUP,ARM
