Запчасти Komatsu PC40MRX-1 КАПОТ (COVER) (КРОМЕ ЯПОН.) ЧАСТИ КОРПУСА

1

22M-54-15542

STAY

1

22M-54-15541

STAY

1

22M-54-15540

STAY

2

01010-81235

BOLT

3

01643-31232

WASHER

4

22M-54-11721

BAR

5

01641-20812

WASHER

6

04052-10833

PIN

7

20B-54-12210

SPRING

8

01023-10406

SCREW

9

20T-54-72660

CAP

10

22M-54-15532

BRACKET

10

22M-54-15531

BRACKET

10

22M-54-15530

BRACKET

11

01571-01016

SEAT

12

01572-21016

SEAT

12

01572-21016

SEAT

13

01573-20206

SEAT

13A

01573-10205

SEAT

13A

01573-10205

SEAT

14

20R-910-1340

SEAT

15

01010-81235

BOLT

16

01010-81250

BOLT

17

198-33-12380

WASHER

18

01643-31232

WASHER

|$39

22M-54-19511

PLATE ASS'Y

|$40

22M-54-19510

PLATE ASS'Y

19

22M-54-19520

PLATE

20

22M-54-19530

SEAL

21

22M-54-19541

SHEET

21

22M-54-19540

SHEET

22

01010-81016

BOLT

23

01643-31032

WASHER

|$49

22M-54-17101

COVER ASS'Y

|$50

22M-54-17100

COVER ASS'Y

24

22M-54-11372

COVER

24

22M-54-11371

COVER

25

22M-54-11670

SEAL

26

22M-54-11680

SEAL

27

22M-54-12330

SHEET

28

22M-54-12590

SEAL

29

01010-81045

BOLT

30

203-54-56970

WASHER

31

22M-54-11521

BRACKET

32

01010-81025

BOLT

33

01643-31032

WASHER

34

20Y-54-11611

STOPPER

35

01580-11008

NUT
