Запчасти Komatsu PC40MR-2 ОХЛАЖД-Е (COVER) СИСТЕМА ОХЛАЖДЕНИЯ

Схема запчастей Komatsu PC40MR-2 - ОХЛАЖД-Е (COVER) СИСТЕМА ОХЛАЖДЕНИЯ
1
2
3
4
5
5A
6
7
8
9
10
10
11
12
13
14
15
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
23A
23B
23C
24
25
26
27
28
28
29
29

Артикул

Название

Примечание

Количество

|$3

22M-03-21801

PLATE ASS'Y

|$4

22M-03-21800

PLATE ASS'Y

1

22M-03-21810

PLATE

2

22M-03-21820

SHEET

3

22M-03-21830

SEAL

4

22M-03-21840

SHEET

5

22M-03-21850

SEAL

5A

22M-03-21940

SHEET

6

01010-81220

BOLT

7

01643-31232

WASHER

8

23S-06-14350

GROMMET

|$16

22M-03-21900

PLATE ASS'Y

9

22M-03-21910

PLATE

10

22M-03-21920

SEAL

11

01010-81220

BOLT

12

01643-31232

WASHER

|$23

22M-03-21691

BRACKET ASS'Y

|$24

22M-03-21690

BRACKET ASS'Y

13

22M-03-21471

SHEET

13

22M-03-21470

SHEET

14

22M-03-21560

BRACKET

15

01010-81220

BOLT

15

01010-81020

BOLT

16

01643-31032

WASHER

|$34

22M-03-21672

BRACKET ASS'Y

|$35

22M-03-21671

BRACKET ASS'Y

17

22M-03-21530

SHEET

18

22M-03-21540

SHEET

19

22M-03-21550

SEAL

20

22M-03-21630

SHEET

21

22M-03-21661

BRACKET

22

22M-03-21771

SHEET

22

22M-03-21770

SHEET

23

22M-03-21791

SEAL

23A

22M-03-21880

SHEET

23B

22M-03-21890

SHEET

23C

22M-03-21970

SHEET

24

01010-81020

BOLT

25

01643-31032

WASHER

|$51

22M-03-22900

COVER ASS'Y

26

22M-03-22910

PLATE

27

22M-03-22920

SHEET

28

01010-81220

BOLT

29

01643-31232

WASHER

Выбрано товаров: 44
