Запчасти Komatsu PC40MR-2 КОРПУС ПОВОРОТА СТРЕЛЫ ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$2

22M-70-00212

SWING BRACKET ASS'Y

|$3

22M-70-00211

SWING BRACKET ASS'Y

1

BRACKET

1

BRACKET

2

22M-70-21530

BUSHING

3

20T-70-81630

BUSHING

4

20T-70-81640

BUSHING

5

22M-70-21522

PIN

6

22L-46-12150

CAP

7

22M-70-21560

PLATE

8

01010-81430

BOLT

9

01643-31445

WASHER

10

22M-70-21540

SPACER, 0.5MM

11

22M-70-21550

SPACER, 0.8MM

12

22M-70-21580

SPACER, 1.0MM

13

22M-70-22870

PIN

13

22N-70-11570

PIN

14

04082-00212

LOCK

15

01010-81230

BOLT

16

01643-31232

WASHER

17

20T-70-81730

SPACER, 1.0MM

18

22M-70-21171

PIN

18

22M-70-21170

PIN

19

20R-70-11250

PLATE

20

01010-81230

BOLT

21

01643-31232

WASHER

22

20T-70-81750

SPACER, 0.5MM

23

22M-70-22970

PIN

23

22M-70-22840

PIN

23

20T-70-71160

PIN

24

20T-70-81650

LOCK

25

01010-81230

BOLT

26

01643-31232

WASHER

27

20T-70-81730

SPACER, 1.0MM

28

01010-82045

BOLT

29

01643-32060

WASHER

30

20T-70-71270

PLATE

31

22M-70-22980

SPACER, 4.5MM

32

22M-70-22990

SPACER, 1.0MM
