Запчасти Komatsu PC40MR-1 MULTI PATERN (КЛАПАН) (WAY)(№-) ГИДРАВЛИКА

|1

22M-62-14201

VALVE ASS'Y

|1

22M-62-14200

VALVE ASS'Y

1

22F-62-13271

PLATE

|1

20T-62-76360

LEVER

2

01252-40618

BOLT

|2

01252-40620

BOLT

3

01643-30623

WASHER

|3

01643-30623

WASHER

4

22F-62-13261

PLATE

|4

22M-62-13190

PLATE

5

22M-62-13240

PLATE

6

20T-62-76440

COVER

7

01252-40620

BOLT

8

07016-00306

SEAL

9

203-62-58950

BODY

10

07000-03028

O-RING

11

07000-02060

O-RING

12

22F-62-13250

PLUG

13

04260-00793

BALL

14

700-84-11750

SPRING

15

20T-62-76430

SHAFT

16

203-62-58980

COVER

17

01252-40616

BOLT

18

201-62-75420

ELBOW

19

07235-10210

ELBOW

20

208-62-18190

ELBOW

21

07002-11423

O-RING

22

21X-62-22270

HOSE¤ 250MM,BLACK

23

22M-62-13230

HOSE

24

21W-62-33240

HOSE,GREEN

25

22M-62-13770

HOSE,YELLOW

26

22M-62-13221

HOSE,YELLOW

27

22M-62-13780

HOSE,WHITE

28

22M-62-13790

HOSE¤ 100MM,BLUE

29

08210-01215

SPIRAL TUBE

30

203-62-52210

RUBBER

31

08034-00519

BAND

32

22M-62-13810

SHEET

33

01010-81025

BOLT

34

01643-31032

WASHER
