Запчасти Komatsu PC40MR-1 НАВЕСНОЕ ОБОРУД-Е ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
20T-62-71150
UNION
2
07002-11823
O-RING
2A
02896-11012
O-RING
3
22N-973-1340
TUBE
|3
22M-973-1440
TUBE
4
22M-973-1434
BRACKET
|4
22M-973-1433
BRACKET
|4
22M-973-1432
BRACKET
5
01010-80825
BOLT
|5
01010-80825
BOLT
6
01643-30823
WASHER
|6
01643-30823
WASHER
7
07283-32236
CLIP
8
01597-01009
NUT
9
01643-31032
WASHER
10
02766-00403
HOSE
|10
22M-973-1350
HOSE¤ 280MM
11
02762-005A6
HOSE
|11
02765-005A4
HOSE
|11
22M-973-1120
HOSE¤ 420MM
12
22N-973-1870
HOSE
|12
22N-973-1750
HOSE¤ 890MM
|12
22M-973-1130
HOSE¤ 600MM
13
22N-973-1350
TUBE
|13
22M-973-1451
TUBE
13A
02896-11015
O-RING
14
01010-81030
BOLT
15
01643-31032
WASHER
16
22M-973-1460
BRACKET
17
01010-81225
BOLT
18
01643-31232
WASHER
19
22N-973-1720
HOSE
|19
22M-973-1334
HOSE
|19
22M-973-1333
HOSE
|19
22M-973-1332
HOSE
20
22N-973-1730
HOSE¤ 2050MM
|20
22M-973-1344
HOSE
|20
22M-973-1343
HOSE
|20
22M-973-1342
HOSE
21
22M-973-1410
CUSHION
|21
22M-973-1410
CUSHION
22
22M-973-1421
PLATE
|22
22M-973-1420
PLATE
23
01010-81025
BOLT
|23
01010-81025
BOLT
24
01643-31032
WASHER
|24
01643-31032
WASHER
25
07095-00526
CUSHION
26
08034-20823
BAND
Выбрано товаров: 49
