Запчасти Komatsu PC40FR-2 РАДИАТОР И МАСЛООХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

1

YM172423-13340

BRACKET

2

YM172423-13370

BRACKET

3

YM172423-13400

SHROUD

4

YM172423-13570

SHROUD

5

YM172116-13410

HOSE,WATER DRAIN

6

YM172164-13520

RUBBER,SEAL

7

YM172734-14620

HOSE,FUEL

8

YM172423-13600

MOUNT

9

YM172423-13610

MOUNT

10

YM172423-13620

PLATE

11

YM129430-44520

RADIATOR

12

YM119259-44570

CAP,RADIATOR

13

YM171064-44510

SUB TANK ASS'Y

14

YM171064-44520

TANK,SUB TANK

15

YM121450-44531

CAP

16

YM124450-44560

CLAMP

17

YM121470-44581

GASKET

18

YM23065-070225

TUBE

19

YM124450-44550

CLAMP,SUB TANK

20

YM172423-13550

WIRE NET,WIRE

21

YM121256-44600

BRACKET,SUB TANK

22

YM121450-49110

VALVE ASS'Y,3-WAY

24

YM121250-49121

PLUG

25

YM24311-000160

O-RING

26

YM124766-59050

CLAMP

27

YM124766-59050

CLAMP

28

YM22137-080000

WASHER

29

YM22137-080000

WASHER

30

YM23010-038000

CLAMP

31

YM26013-080162

BOLT

32

YM26013-100252

BOLT

33

YM26051-080002

NUT

34

YM26013-060122

BOLT

35

YM26013-080162

BOLT

36

YM26013-080202

BOLT

37

YM26013-080202

BOLT

38

YM26013-080162

BOLT

39

YM26013-080202

BOLT

40

YM26022-080162

SCREW

41

YM933168-55770

BAND

42

YM172423-74800

OIL COOLER

43

YM172164-13201

HOSE

44

YM172164-13210

HOSE

45

YM172122-13310

CUSHION,RADIATOR

46

YM172141-14610

HOSE,FUEL

47

YM172423-13650

SEAL

48

YM172175-65770

SEAL

49

YM172183-14650

CLAMP

50

YM172423-13580

SEAL

51

YM172423-13660

SEAL

52

YM172164-13240

HOSE,(COOLER SPEC.)

53

YM172122-13400

CLAMP,(COOLER SPEC.)

54

YM194250-51660

BAND,(COOLER SPEC.)

55

YM26013-080162

BOLT,(COOLER SPEC.)
