Запчасти Komatsu PC400ST-6LC КАПОТ(№8-) ЧАСТИ КОРПУСА

1

208-54-67322

COVER

2

01010-81230

BOLT

|2

01010-51230

BOLT

3

175-54-34170

WASHER

|3

01643-31232

WASHER

4

208-54-67335

COVER

|4

208-54-67334

COVER

5

01010-51230

BOLT

6

175-54-34170

WASHER

|6

01643-31232

WASHER

7

208-54-67340

COVER

7A

205-46-63280

HINGE

7B

426-54-11961

LOCK

8

203-54-56630

ROD

9

04050-11612

PIN

10

01643-30623

WASHER

11

20Y-54-29650

BRACKET

12

01010-81220

BOLT

|12

01010-51220

BOLT

13

01643-31232

WASHER

14

01010-81230

BOLT

|14

01010-51230

BOLT

15

01643-31232

WASHER

16

208-54-67354

COVER

17

01010-81230

BOLT

|17

01010-51230

BOLT

18

175-54-34170

WASHER

19

208-54-67362

COVER

19A

205-46-63280

HINGE

19B

208-54-67912

SHEET

19C

426-54-11961

LOCK

20

208-54-67390

BAR

21

04050-13022

PIN

22

01643-31445

WASHER

23

208-54-67372

COVER

24

01010-81230

BOLT

|24

01010-51230

BOLT

25

175-54-34170

WASHER

|25

01643-31232

WASHER

26

208-54-67460

HANDRAIL

27

01010-81230

BOLT

|27

01010-51230

BOLT

28

01643-31232

WASHER

29

208-54-67580

COVER

30

01010-81230

BOLT

|30

01010-51230

BOLT

31

01643-31232

WASHER

32

207-54-61141

PLATE

33

20Y-54-12941

PLATE

34

207-54-31870

BRACKET

35

20Y-54-12920

CLAMP

36

01010-81020

BOLT

|36

01010-51020

BOLT

37

01643-31032

WASHER

38

01010-81220

BOLT

|38

01010-51225

BOLT

39

01643-31232

WASHER

40

20Y-54-12760

SEAL
