Запчасти Komatsu PC400ST-6LC КАПОТ(№-7) ЧАСТИ КОРПУСА

1

208-54-67321

COVER

2

01010-51230

BOLT

3

01643-31232

WASHER

4

208-54-67330

COVER

5

01010-51230

BOLT

6

01643-31232

WASHER

7

208-54-67340

COVER

8

205-46-63280

HINGE

9

426-54-11961

LOCK

10

203-54-56630

ROD

11

04050-11612

PIN

12

01643-30623

WASHER

13

20Y-54-29650

BRACKET

14

01010-51220

BOLT

15

01643-31232

WASHER

16

01010-51230

BOLT

17

01643-31232

WASHER

18

208-54-67351

COVER

19

01010-51230

BOLT

20

175-54-34170

WASHER

21

208-54-67361

COVER

22

205-46-63280

HINGE

23

208-54-67912

SHEET

24

426-54-11961

LOCK

25

208-54-67390

BAR

26

04050-13022

PIN

27

01643-31445

WASHER

28

20Y-54-29650

BRACKET

29

01010-51220

BOLT

30

01643-31232

WASHER

31

01010-31230

BOLT

32

01643-31232

WASHER

33

208-54-67370

COVER

34

01010-51230

BOLT

35

01643-31232

WASHER

36

208-54-67460

HANDRAIL

37

01010-51230

BOLT

38

01643-31232

WASHER

39

208-54-67580

COVER

40

01010-51230

BOLT

41

01643-31232

WASHER
