Запчасти Komatsu PC400ST-6 ЦИЛИНДР РУКОЯТИ(ДЛЯ .M СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

208-63-X7320

ARM CYLINDER GROUP

|1

208-63-07320

ARM CYLINDER ASS'Y

1

208-63-64540

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07020-00900

FITTING

|4

07020-00000

FITTING

5

208-63-64520

ROD

6

707-76-11130

BUSHING

7

07145-00110

SEAL,DUST (KIT)

8

07020-00000

FITTING

|8

07020-00675

FITTING

9

707-71-60350

PLUNGER

|9

707-71-60310

PLUNGER

10

04260-01270

BALL

11

707-71-91050

SCREW

12

707-27-18660

HEAD

13

195-63-93170

SEAL,DUST (KIT)

14

07179-13136

RING,SNAP

15

707-52-90950

BUSHING

16

707-51-12030

PACKING,ROD (KIT)

17

707-51-12630

RING,BUFFER (KIT)

18

07001-05180

RING,BACK-UP (KIT)

19

07000-15180

O-RING (KIT)

20

01011-82400

BOLT

21

707-88-75410

WASHER

22

707-36-18500

PISTON

23

707-40-18870

SPACER

24

01252-31455

BOLT

25

707-44-18280

RING,PISTON (KIT)

26

707-39-18830

RING,WEAR (KIT)

27

707-44-18920

RING

28

707-35-52940

RING,BACK-UP (KIT)

29

07000-12100

O-RING (KIT)

30

208-63-64570

TUBE

31

208-63-64580

TUBE

32

01010-51060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING (KIT)

35

208-63-64400

BRACKET

36

208-63-64590

BRACKET

37

01010-51240

BOLT

38

01643-51232

WASHER

39

07283-23442

CLIP

40

01643-31032

WASHER

41

01599-01011

NUT
