Запчасти Komatsu PC400LCSE-8R СТАРТЕР (7.KW)(ВНУТР. ЧАСТИ) A

|$1

600-813-6632

STARTING MOTOR ASS'Y, (7.5KW)

1

KD0-23904-0070

PIN

2

KD0-23927-0071

HOLDER

3

KD1-23914-0020

RING, CLIP

4

KD1-23181-0020

STOPPER, PINION

5

KD1-23111-0160

SHAFT

6

KD0-23310-0860

BRACKET

7

KD1-23500-0170

CLUTCH ASS'Y, OVER RUNNING

8

KD0-23951-0301

PACKING

9

KD0-23320-0220

SHIFT LEVER A.

10

KD1-0456-60067

BEARING, BALL

11

KD0-23951-0331

PACKING

12

KD0-23600-0430

CENTER BRACKET A.

13

KD0-23611-0690

BRACKET, CENTER

14

KD1-09211-0980

O-RING

15

KD0-23921-0230

WASHER

16

KD1-0454-62047

BEARING, BALL

17

KD0-0274-06202

BOLT

18

KD1-23951-0020

PACKING

19

KD1-0400-20100

PIN, STRAIGHT

20

KD0-23100-0251

ARMATURE ASS'Y

21

KD0-47100-4800

MAGNETIC SWITCH A.

22

KD0-09271-3620

NAME PLATE

23

KD0-23200-0331

YOKE ASS'Y

24

KD0-47761-2691

COVER

25

KD1-23913-0040

SPRING, BRUSH

26

KD0-23740-0250

BRUSH ASS'Y

27

KD0-23750-0250

BRUSH HOLDER ASS'Y

28

KD1-0505-00601

O-RING

29

KD1-47921-0790

WASHER

30

KD0-09001-4580

BOLT

31

KD1-0454-62007

BEARING, BALL

32

KD0-23700-0130

REAR BRACKET ASS'Y

33

KD1-0240-06305

BOLT

34

KD1-23921-0130

WASHER

35

KD1-23921-0140

WASHER

36

KD1-23941-0040

WASHER, INSULATE

37

KD1-0240-08405

BOLT

38

KD1-0335-08002

WASHER, SPRING

39

KD1-0330-08022

WASHER, PLAIN

40

KD0-23901-0170

BOLT

41

KD1-0335-06002

WASHER, SPRING

42

KD1-0330-06012

WASHER, PLAIN

43

KD0-0270-06402

BOLT

44

KD1-47927-1250

HOLDER
