Запчасти Komatsu PC400LCSE-8R ОСНОВН. КЛАПАН ( ACTUTOR) (/) Y

|$1

723-48-27504

CONTROL VALVE

|$2

723-48-27503

CONTROL VALVE

|$3

723-48-27502

CONTROL VALVE

|$4

723-48-27501

CONTROL VALVE

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.Y1664-01A0 TO Y1664-23A0.

|$7

723-40-66300

VALVE ASS'Y

1

CASE

2

SEAT

3

SEAT

4

BALL

5

PLUG

6

723-90-76501

VALVE ASS'Y. SUCTION AND SAFETY

7

07000-13024

O-RING

8

723-90-61700

VALVE ASS'Y. SUCTION AND SAFETY

9

07000-13024

O-RING
