Запчасти Komatsu PC400LCSE-8R ОСНОВН. КЛАПАН ( ACTUTOR) (/) Y

Схема запчастей Komatsu PC400LCSE-8R - ОСНОВН. КЛАПАН ( ACTUTOR) (/) Y
22
30
18
14
23
8
2
7
9
3
9
5
1
6
4
12
14
11
13
10
28
19
29
20
21
17
32
31
34
26
27
31
24
31
25
15
16
31
31
31
33
34

Артикул

Название

Примечание

Количество

|$1

723-48-27504

CONTROL VALVE

|$2

723-48-27503

CONTROL VALVE

|$3

723-48-27502

CONTROL VALVE

|$4

723-48-27501

CONTROL VALVE

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.Y1664-01A0 TO Y1664-23A0.

1

723-40-71201

VALVE ASS'Y

|$8

723-40-71800

VALVE ASS'Y

|$9

723-40-91600

VALVE ASS'Y, RELIEF

2

702-16-53920

O-RING

3

07002-11623

O-RING

4

BLOCK

5

SPOOL

6

SPRING

7

702-21-55620

PLUG

8

708-8H-11530

PLUG

9

07002-11423

O-RING

10

702-21-55710

SEAT

11

702-21-55720

SPRING

12

04260-00793

BALL

13

07000-11009

O-RING

14

PLUG

15

723-40-71430

VALVE

16

702-21-55460

SPRING

17

702-21-55420

O-RING

18

702-21-55520

O-RING

19

702-21-55440

O-RING

20

702-21-53140

FILTER

|$29

702-21-53120

FILTER

21

07000-12011

O-RING

22

01252-61040

BOLT

23

01643-51032

WASHER

24

708-8H-11530

PLUG

25

07002-11423

O-RING

26

702-21-55620

PLUG

27

07002-11423

O-RING

28

708-8E-16160

PLUG

29

07002-11023

O-RING

30

07000-12011

O-RING

31

PLUG

32

01010-61460

BOLT

33

01010-61470

BOLT

34

01643-31445

WASHER

Выбрано товаров: 43
