Запчасти Komatsu PC400LCSE-8R ОСНОВН. КЛАПАН (/) Y

|$1

723-47-27504

CONTROL VALVE

|$2

723-47-27503

CONTROL VALVE

|$3

723-47-27502

CONTROL VALVE

|$4

723-47-27501

CONTROL VALVE

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.Y1662-01A0 TO Y1662-20A0.

|$7

BODY SUB ASS'Y

|$8

BODY SUB ASS'Y

1

723-46-11910

BLOCK

2

723-46-15510

O-RING

3

01252-60865

BOLT

4

723-46-18730

PLATE

5

07000-12021

O-RING

6

07000-12011

O-RING

7

01010-81040

BOLT

8

01643-51032

WASHER

9

723-90-69100

VALVE ASS'Y, SUCTION AND SAFETY

10

07002-13634

O-RING
