Запчасти Komatsu PC400LCSE-8R ОСНОВН. КЛАПАН (/) Y

|$1

723-47-27504

CONTROL VALVE

|$2

723-47-27503

CONTROL VALVE

|$3

723-47-27502

CONTROL VALVE

|$4

723-47-27501

CONTROL VALVE

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.Y1662-01A0 TO Y1662-20A0.

|$7

BODY SUB ASS'Y

|$8

723-46-09102

BODY SUB ASS'Y

1

BLOCK,VALVE

|$10

BLOCK,VALVE

2

SPOOL

|$12

SPOOL

3

SPOOL

|$14

SPOOL

4

SPOOL

5

SPOOL

6

SPOOL

7

SPOOL

|$19

SPOOL

8

723-46-15130

PLUG

9

723-46-15140

PLUG

10

07002-10823

O-RING

11

PLUG

12

07002-11423

O-RING

13

SEAL

14

SEAL

15

708-7T-16460

BALL

16

723-46-15120

RETAINER

17

723-46-15690

RETAINER

18

723-46-14110

SPRING

19

723-46-14170

SPRING

20

723-46-14131

SPRING
