МОТОР ПОВОРОТА (/)

Запчасти Komatsu PC400LCSE-8R МОТОР ПОВОРОТА (/) Y

Схема запчастей Komatsu PC400LCSE-8R - МОТОР ПОВОРОТА (/) Y
7
5
1
6
4
3
2
7
5
1
6
4
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

706-7K-01160

SWING MOTOR ASS'Y

|$2

706-7K-01050

SWING MOTOR ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1640-01A1 TO Y1640-03A1.

1

702-77-02170

VALVE ASS'Y, RELIEF

|$6

702-77-02120

VALVE ASS'Y, RELIEF

2

07000-F3022

O-RING

3

07001-03022

RING, BACK-UP

4

07002-13634

O-RING

5

706-7G-71290

PLATE

|$11

706-7G-71191

PLATE

6

07000-11009

O-RING

7

01252-60825

BOLT

|$1

706-7K-01160

SWING MOTOR ASS'Y

|$2

706-7K-01050

SWING MOTOR ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1640-01A1 TO Y1640-03A1.

1

702-77-02170

VALVE ASS'Y, RELIEF

|$6

702-77-02120

VALVE ASS'Y, RELIEF

2

07000-F3022

O-RING

3

07001-03022

RING, BACK-UP

4

07002-13634

O-RING

5

706-7G-71290

PLATE

|$11

706-7G-71191

PLATE

6

07000-11009

O-RING

7

01252-60825

BOLT
