Запчасти Komatsu PC400LCSE-8R МОТОР ПОВОРОТА (/) Y

Схема запчастей Komatsu PC400LCSE-8R - МОТОР ПОВОРОТА (/) Y
14
13
26
2
12
23
3
24
17
25
4
16
19
15
5
18
6
20
7
1
8
22
21
9
10
11

Артикул

Название

Примечание

Количество

|$1

706-7K-01160

SWING MOTOR ASS'Y

|$2

706-7K-01050

SWING MOTOR ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1640-01A1 TO Y1640-03A1.

|$5

706-7K-03140

MOTOR SUB ASS'Y

|$6

706-7K-03030

MOTOR SUB ASS'Y

1

706-7K-41610

SHAFT

2

706-77-43890

BEARING

|$9

706-77-43880

BEARING

3

706-7K-41810

SPACER

4

706-77-42051

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

|$15

SPACER, 2.3MM

|$16

SPACER, 2.5MM

|$17

SPACER, 2.7MM

8

04064-06525

RING, SNAP

9

706-8J-41420

SEAL, OIL

|$20

706-7K-41650

SEAL, OIL

10

706-7K-41920

SPACER

11

04065-07525

RING

12

706-7K-41210

BLOCK, CYLINDER

13

706-7K-41710

PLATE, VALVE

14

708-18-13230

PIN

15

706-7K-41120

SHAFT, CENTER

16

706-77-42130

RING, CENTER

17

706-7K-41140

SPRING

|$29

706-7K-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7K-41160

PISTON SUB ASS'Y

21

706-7K-91340

PLATE

22

706-7K-91350

DISC

23

706-7K-91111

PISTON, BRAKE

24

07000-B5230

O-RING

|$37

07000-15230

O-RING

25

706-86-90290

O-RING

|$39

708-8H-15220

O-RING

26

706-7K-91360

SPRING

Выбрано товаров: 40
