Запчасти Komatsu PC400LCSE-8R ЦИЛИНДР КОВША ( ЧАС.)(STD) Y

|$1

707-01-0AG80

CYLINDER ASSY

1

707-13-18920

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL, DUST (KIT)

4

07020-00675

FITTING, GREASE

5

707-58-12650

ROD

6

707-76-11130

BUSHING

7

07145-00110

SEAL,DUST (KIT)

8

07020-00000

FITTING, GREASE

9

707-27-18930

HEAD

10

707-56-12740

SEAL, DUST (KIT)

|$12

195-63-93170

SEAL,DUST (KIT)

11

07179-13136

RING,SNAP

12

707-52-90981

BUSHING

|$15

707-52-90980

BUSHING

13

07179-13126

RING,SNAP

14

707-51-12030

PACKING,ROD (KIT)

15

707-51-12650

RING,BUFFER (KIT)

16

707-35-91840

RING,BACK-UP (KIT)

17

07000-15175

O-RING (KIT)

18

01011-82400

BOLT

19

707-88-75410

WASHER

20

707-36-18520

PISTON

21

01310-01225

SCREW

22

707-44-18250

RING,PISTON (KIT)

23

707-39-18510

RING,WEAR (KIT)

24

707-44-18920

RING

25

07001-05110

RING,BACK-UP (KIT)

26

07000-B5110

O-RING (KIT)

27

707-86-13080

TUBE

28

208-63-73580

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING

32

707-88-51340

BRACKET

|$36

707-88-28260

BRACKET

33

707-88-26140

BRACKET

34

07283-33442

CLAMP

35

01643-31032

WASHER

36

01597-01009

NUT

37

707-88-28270

BRACKET

38

07372-21240

BOLT

39

01643-51232

WASHER
