Запчасти Komatsu PC400LCSE-8R ОСНОВН. НАСОС (7/) Y

|$1

708-2H-00450

PUMP ASS'Y

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIGS.Y1600-01A0 T0 Y1600-12A0.

|$4

708-2H-01450

PUMP SUB ASS'Y

1

708-2H-32210

SHAFT

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

|$8

WASHER, 3.0MM

|$9

WASHER, 3.1MM

|$10

WASHER, 3.2MM

4

708-17-12780

RING, SNAP

|$12

708-2H-04760

BLOCK ASS'Y, REAR

5

BLOCK, CYLINDER

6

PLATE,VALVE

7

708-18-13230

PIN

8

04065-05820

RING

9

708-2H-33140

SEAT

10

708-2H-33150

SPRING

11

708-2H-23141

SEAT

12

708-2H-23350

GUIDE, RETAINER

13

708-2H-23360

PIN

14

708-2H-33343

RETAINER, SHOE

15

708-2H-33311

PISTON SUB ASS'Y

|$24

708-2H-04690

CRADLE SUB ASS'Y

16

CRADLE

17

CAM, ROCKER

18

04020-01434

PIN, DOWEL

19

07000-B1009

O-RING

20

01252-61235

BOLT

21

708-2H-32130

COUPLING

22

708-2H-12420

RING
