Запчасти Komatsu PC400LCSE-8R ТОПЛИВН. НАСОС (/)(НАСОС)(ВНУТР. ЧАСТИ)(№9-9) A

|$1

6251-71-1120

FUEL PUMP ASS'Y

|$2

ND094100-0460

BODY ASS'Y

1

ND094110-0210

HOUSING ASS'Y

2

ND094040-0270

ELEMENT ASS'Y

3

ND094086-0090

O-RING

4

ND094137-0010

GASKET

5

ND094140-0040

VALVE ASS'Y

6

ND094086-0100

O-RING

7

ND949013-5880

WASHER

8

ND921560-8081

NUT

9

ND094162-0040

SEAT, SPRING UPPER

10

ND094164-0010

SPRING, PLUNGER

11

ND094165-0021

SEAT, SPRING LOWER

12

ND094170-0100

TAPPET ASS'Y

13

ND094191-0161

CAMSHAFT

14

ND949101-0230

BEARING, ROLLER

15

ND094104-0100

COVER, BEARING

16

ND949150-3030

SEAL, OIL

17

ND094086-0120

O-RING

18

ND094095-0100

SHIM, T=0.05MM

|$21

ND094095-0130

SHIM, T=0.10MM

|$22

ND094095-0140

SHIM, T=0.20MM

|$23

ND094095-0150

SHIM, T=0.30MM

|$24

ND094095-0160

SHIM, T=0.50MM

19

ND094092-0010

WASHER

20

ND949044-3320

BOLT

21

ND094086-0110

O-RING

22

ND094086-0130

O-RING

23

ND094093-0050

SHIM, T=0.40MM

|$30

ND094093-0060

SHIM, T=0.60MM

|$31

ND094093-0070

SHIM, T=0.80MM

|$32

ND094093-0080

SHIM, T=1.00MM

24

ND949979-1300

SENSOR ASS'Y

|$34

ND949140-6310

O-RING

25

ND094096-0050

SHIM, T=0.15MM

|$36

ND094096-0060

SHIM, T=0.20MM

|$37

ND094096-0070

SHIM, T=0.25MM

|$38

ND094096-0080

SHIM, T=0.40MM

26

ND902000-6081

WASHER

27

ND901070-6161

BOLT

28

ND090310-0500

VALVE ASS'Y, OVERFLOW

29

ND090222-0070

WASHER

30

ND949180-0310

SCREW
