Запчасти Komatsu PC400LCSE-8R ПОРШЕНЬ И ШАТУН A

Схема запчастей Komatsu PC400LCSE-8R - ПОРШЕНЬ И ШАТУН A
4
5
6
1
2
3
7
9
12
13
11
8
10
3

Артикул

Название

Примечание

Количество

1

6251-31-2510

PISTON

2

6151-31-2410

PIN, PISTON

3

04065-04818

RING, SNAP

|$4

6251-31-2030

PISTON RING ASS'Y,PER CYLINDER

4

RING, TOP

5

RING, 2ND

6

RING, OIL

|$8

6251-31-3100

CONNECTING ROD ASS'Y

7

ROD, CONNECTING, CONNECTING

8

CAP, CONNECTING ROD

9

6251-31-3130

BUSHING

10

6150-31-3310

BOLT

11

02400-10413

PIN, DOWEL

|$14

6151-31-3050

METAL ASS'Y, STANDARD

|$15

6151-39-3050

METAL ASS'Y, UNDERSIZE 0.25MM

|$16

6151-38-3050

METAL ASS'Y, UNDERSIZE 0.50MM

|$17

6151-37-3050

METAL ASS'Y, UNDERSIZE 0.75MM

|$18

6151-36-3050

METAL ASS'Y, UNDERSIZE 1.00MM

12

METAL, UPPER STANDARD

|$20

METAL, UPPER UNDERSIZE 0.25MM

|$21

METAL, UPPER UNDERSIZE 0.50MM

|$22

METAL, UPPER UNDERSIZE 0.75MM

|$23

METAL, UPPER UNDERSIZE 1.00MM

13

METAL, LOWER STANDARD

|$25

METAL, LOWER UNDERSIZE 0.25MM

|$26

METAL, LOWER UNDERSIZE 0.50MM

|$27

METAL, LOWER UNDERSIZE 0.75MM

|$28

METAL, LOWER UNDERSIZE 1.00MM

Выбрано товаров: 28
