Запчасти Komatsu PC400LCSE-8R КАБИНА (ПОЛ) (CONSOL. R.H) K

1

20Y-43-41314

FRAME R.H

|$2

20Y-43-41313

FRAME R.H

2

01010-D1230

BOLT

3

01643-71232

WASHER

4

20Y-43-41631

SHEET

5

22U-43-23251

SHEET

6

22U-43-23290

CLIP

7

20Y-43-41323

COVER

8

20Y-43-41661

SHEET

9

01010-80616

BOLT

10

01643-30623

WASHER

11

20Y-43-41290

COLLAR

|$13

20Y-43-42330

COVER

12

COVER

13

20Y-43-42170

TAPE

14

01245-00616

SCREW

15

01643-70623

WASHER

16

01010-80616

BOLT

17

01643-30623

WASHER

18

01435-00612

BOLT

19

20Y-43-41290

COLLAR

|$22

20Y-43-42350

COVER

20

COVER

21

20Y-43-42170

TAPE

22

01245-00616

SCREW

23

01643-70623

WASHER

24

20Y-43-41290

COLLAR

25

01245-00616

SCREW

26

01643-70623

WASHER

27

09415-02512

CAP

28

20Y-43-41991

BRACKET

29

20Y-43-42180

TAPE

30

08086-20000

SWITCH

31

20Y-43-41740

PLATE

32

20Y-43-41750

WASHER

33

20Y-43-41790

WASHER

34

20Y-43-41671

SHEET

35

08034-20519

BAND

36

22U-06-22380

POTENTIOMETER

37

22U-06-22460

SPRING

38

20Y-43-41781

KNOB

|$42

20Y-43-41780

KNOB

39

20Y-06-42110

SWITCH, SWING LOCK

40

20Y-06-42121

SWITCH, LIGHT

41

21T-06-33760

SWITCH ASS'Y, MACHINE PUSH-UP

42

207-06-76130

WIRING HARNESS
