Запчасти Komatsu PC400LCSE-8R БЛОК ЦИЛИНДРОВ A

|$1

6251-21-1100

CYLINDER BLOCK ASS'Y

1

BLOCK, CYLINDER

2

6150-21-1490

BUSHING, CAMSHAFT

3

6150-21-1210

CAP, MAIN METAL, NO.1,2,3,4,5,6

|$5

6150-29-1210

CAP, MAIN METAL,NO.1,2,3,4,5,6

4

6150-21-1250

CAP, MAIN METAL, NO.7

|$7

6150-29-1250

CAP, MAIN METAL,NO.7

5

04020-00514

PIN, DOWEL

6

6150-21-1710

BOLT

7

01643-31645

WASHER

8

07043-70108

PLUG

9

07043-70211

PLUG

10

07043-70617

PLUG

11

07040-12414

PLUG

12

07040-13016

PLUG

13

07002-23034

O-RING

14

07002-22434

O-RING

15

07046-43016

PLUG

16

07046-44016

PLUG

17

6154-21-1981

PLUG

18

07000-72022

O-RING

19

07046-43516

PLUG

20

04020-00820

PIN. DOWEL

21

6150-21-1170

TUBE

22

6150-41-2430

PIN

23

6150-41-2440

PIN

24

04025-00408

PIN, SPRING

25

6150-21-4770

PIN, DOWEL

26

6150-41-2430

PIN

27

04025-00512

PIN, SPRING

28

6154-21-2220

LINER, CYLINDER

29

6150-21-2230

O-RING, LOWER

30

6251-21-2240

O-RING, CENTER

31

6150-21-2250

SEAL, CREVICE

32

6154-21-1810

NOZZLE, PISTON COOLING

33

01435-00816

BOLT
