Запчасти Komatsu PC400LC-8R ГИДР. БАК., БАК (№7-) ГИДР. БАК., БЕЗ ANTI-DROP КЛАПАН

1

208-60-75111

Tank

1

208-60-75110

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

07044-12412

Plug

5

07002-12434

O-ring

6

02783-10628

Elbow

7

07002-12434

O-ring

8

02896-11018

O-ring

9

02782-10315

Elbow

10

07002-12034

O-ring

11

02896-11009

O-ring

12

207-62-72110

Union

13

07002-13334

O-ring

14

207-62-64740

O-ring

15

02782-10422

Elbow

16

07002-12034

O-ring

17

02896-11012

O-ring

18

02783-10210

Elbow

19

07002-11423

O-ring

20

02896-11008

O-ring

21

208-60-71123

Element, Transmission Oil Filter

22

07069-25400

Strainer

23

208-60-71160

Valve Assembly

24

07069-34075

Spring

25

208-60-71130

Plate

26

07000-15210

O-ring

27

01010-81225

Bolt

28

01643-31232

Washer

|$29

208-60-71140

Strainer Assembly

29

208-60-71150

Rod Assembly

30

12R-60-11230

Spring

31

20Y-60-21320

Holder

32

22B-60-11160

Strainer

33

208-60-61190

Cover

34

07000-15180

O-ring

35

01010-81225

Bolt

36

01643-31232

Washer
