Запчасти Komatsu PC400LC-8 A-BX ГЕНЕРАТОР ( A) ДВИГАТЕЛЬ

|$0

600-825-5150

ALTERNATOR (50 A)

1

KD0-35100-0300

ROTOR

2

KD1-33923-0790

COLLAR

3

KD0-35923-0160

COLLAR

4

KD0-09201-0980

BEARING, BALL

5

KD0-35200-0440

STATOR

6

KD0-35300-0190

BRACKET

7

KD0-09201-0881

BEARING, BALL

8

KD0-35926-0070

RETAINER

9

KD0-35951-0060

PACKING

10

KD0-35926-0090

RETAINER

11

KD1-33926-0730

RETAINER

12

KD0-0275-06802

BOLT

13

KD0-35411-0560

PULLEY

14

KD0-35421-0170

FAN

15

KD1-0330-16012

WASHER, PLAIN

16

KD1-0335-16002

WASHER, SPRING

17

KD0-0280-16022

NUT

18

KD0-35120-0230

FIELD COIL

|$19

KD0-35700-0821

REAR BRACKET

19

KD0-35710-1010

BRACKET, REAR

20

KD0-35730-0510

RECTIFIER

21

KD0-09170-2501

CONDENSER

22

KD0-35943-0150

BUSHING, INSULATE

23

KD0-35943-0130

BUSHING, INSULATE

24

KD0-35943-0160

BUSHING, INSULATE

25

KD0-35943-0140

BUSHING, INSULATE

26

KD0-35923-0170

COLLAR

27

KD0-35784-0210

BAR, CONNECT

28

KD0-35784-0290

BAR, PLATE

29

KD7-35719-0201

REGULATOR

30

KD0-35761-0250

COVER
