Запчасти Komatsu PC400LC-8 A-DY7 ТОПЛИВН. НАСОС (/) ДВИГАТЕЛЬ

|$0

6251-71-1121

FUEL PUMP

|$1

ND094100-0460

BODY

1

ND094110-0210

HOUSING

2

ND094040-0370

PCV ELEMENT

3

ND094086-0090

O-RING

4

ND094140-0040

VALVE

5

ND094086-0100

O-RING

6

ND949013-5880

WASHER

7

ND92156-08081

NUT

8

ND094162-0040

SEAT, SPRING UPPER

9

ND094164-0010

SPRING, PLUNGER

10

ND094165-0021

SEAT, SPRING, LOWER

11

ND094170-0100

TAPPET

12

ND094191-0161

CAMSHAFT

13

ND949101-0230

BEARING, ROLLER

14

ND094104-0100

COVER, BEARING

15

ND949150-3030

SEAL, OIL

16

ND094086-0120

O-RING

17

ND094095-0100

SHIM, 0.05 MM

N/I

ND094095-0130

SHIM, 0.10 MM

N/I

ND094095-0140

SHIM, 0.20 MM

N/I

ND094095-0150

SHIM, 0.30 MM

N/I

ND094095-0160

SHIM, 0.50 MM

18

ND094092-0010

WASHER

19

ND949044-3320

BOLT

20

ND094086-0110

O-RING

21

ND094086-0130

O-RING

22

ND094093-0050

SHIM, 0.40 MM

N/I

ND094093-0060

SHIM, 0.60 MM

N/I

ND094093-0070

SHIM, 0.80 MM

N/I

ND094093-0080

SHIM, 1.00 MM

23

ND949979-1300

SENSOR

N/I

ND949140-6310

O-RING

24

ND094096-0050

SHIM, 0.15 MM

N/I

ND094096-0060

SHIM, 0.20 MM

N/I

ND094096-0070

SHIM, 0.25 MM

N/I

ND094096-0080

SHIM, 0.40 MM

25

ND90200-06081

WASHER

26

ND90107-06161

BOLT

27

ND090310-0500

VALVE, OVERFLOW

28

ND090222-0070

WASHER

29

ND949180-0310

SCREW

30

ND090222-0120

WASHER

31

ND949180-0060

SCREW

32

ND949018-0350

WASHER

33

ND090317-0480

PLUG, SCREW

34

ND090207-0100

RING

35

ND090244-0010

SCREW

36

ND949010-3020

WASHER

37

ND094086-0210

O-RING
