Запчасти Komatsu PC400LC-8 T-A ЦИЛИНДР РУКОЯТИУСИЛ. СТРЕЛА РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0F711

CYLINDER

1

707-13-18760

CYLINDER

2

707-76-11220

BUSHING

3

07145-00110

SEAL, DUST

4

707-58-13190

ROD

5

707-76-11220

BUSHING

6

07145-00110

SEAL, DUST

7

707-71-31680

COLLAR

8

707-35-91840

RING, BACK-UP

9

07000-15175

O-RING

10

707-71-61430

PLUNGER

11

707-71-70340

PLUNGER

12

04260-00952

BALL

13

707-71-91230

CAP

14

707-27-18180

HEAD

15

707-56-13520

SEAL, DUST

16

07179-14146

RING, SNAP

17

707-52-91070

BUSHING

18

07179-13136

RING, SNAP

19

707-51-13030

PACKING, ROD

20

707-51-13640

RING, BUFFER

21

707-35-91840

RING, BACK-UP

22

07000-15175

O-RING

23

01011-82400

BOLT

24

707-88-75410

WASHER

25

707-36-18530

PISTON

26

01310-01225

SCREW

27

707-44-18280

RING, PISTON

28

707-39-18510

RING, WEAR

29

707-44-18920

RING

30

07001-05120

RING, BACK-UP

31

07000-15120

O-RING

32

707-86-12590

TUBE

33

707-86-11610

BLOCK

34

707-88-02960

PLATE

35

07372-21060

BOLT

36

01643-51032

WASHER

37

01011-81005

BOLT

38

01643-51032

WASHER

39

07000-13035

O-RING

40

707-88-25450

BRACKET

41

707-88-21880

BAND

42

07372-21240

BOLT

43

01643-51232

WASHER

44

07283-33442

CLIP

45

01643-31032

WASHER

46

01597-01009

NUT

|$47

707-99-69710

SERVICE KIT
