Запчасти Komatsu PC400LC-8 H8-A КЛАПАН PPCДЛЯ -НАВЕСН. ОБОРУД ГИДРАВЛИКА

|$0

702-16-04290

PILOT VALVE

1

NSS

BODY, VALVE

2

NSS

VALVE

3

702-16-51140

SHIM, 0.30 MM

N/I

702-16-54670

SHIM, 0.20 MM

4

702-16-54550

SPRING

5

702-16-54571

RETAINER

6

702-16-54560

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

702-16-54580

COLLAR

10

702-16-54590

O-RING

11

NSS

LEVER

12

NSS

PLATE

13

NSS

SHAFT

14

702-16-54641

BOOT

15

01252-30625

BOLT

16

702-16-54660

PLATE

17

702-16-54650

PLATE

18

702-21-07610

SOLENOID VALVE

19

700-22-11410

O-RING

20

702-21-39450

O-RING

21

07000-11008

O-RING

22

07000-12012

O-RING

23

NSS

BODY

24

01252-60612

BOLT

25

203-60-62220

BOLT
