Запчасти Komatsu PC400LC-8 H-8A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН (/) ГИДРАВЛИКА

1

723-40-91600

VALVE, RELIEF

2

702-16-53920

O-RING

3

07002-11623

O-RING

4

NSS

BLOCK

5

NSS

SPOOL

6

NSS

SPRING

7

702-21-55620

PLUG

8

708-8H-11530

PLUG

9

07002-11423

O-RING

10

702-21-55710

SEAT

11

702-21-55720

SPRING

12

04260-00793

BALL

13

07000-11009

O-RING

14

NSS

PLUG

15

723-40-71430

VALVE

16

702-21-55460

SPRING

17

702-21-55420

O-RING

18

702-21-55520

O-RING

19

702-21-55440

O-RING

20

702-21-53120

FILTER

21

07000-12011

O-RING

22

01252-61040

BOLT

23

01643-51032

WASHER

24

708-8H-11530

PLUG

25

07002-11423

O-RING

26

702-21-55620

PLUG

27

07002-11423

O-RING

28

708-8E-16160

PLUG

29

07002-11023

O-RING

30

07000-12011

O-RING

31

NSS

PLUG

32

01010-61460

BOLT

33

01010-61470

BOLT

34

01643-31445

WASHER
