Запчасти Komatsu PC400LC-8 РУКОЯТЬ, ВНУТР. ЧАСТИ, ЦИЛИНДР КОВША (№7-) РУКОЯТЬ, MM, ЧАС. СИСТ. СМАЗКИ ТИП, ДЛЯ SUPER EARTHMOVER

|$0

707-01-0AG80

Cylinder Assembly

1

707-13-18920

Cylinder

2

707-58-12650

Rod

3

707-76-11130

Bushing

4

07145-00110

Seal, Dust, (Kit : K12)

5

07020-00675

Fitting, Grease

6

707-76-11130

Bushing

7

07145-00110

Seal, Dust, (Kit : K12)

8

07020-00000

Fitting, Grease

9

707-27-18930

Head, Cylinder

10

195-63-93170

Seal, Dust, (Kit : K12)

11

07179-13136

Ring, Snap

12

707-51-12030

Packing, Rod, (Kit : K12)

13

707-51-12650

Ring, Buffer, (Kit : K12)

14

707-52-90980

Bushing

15

07000-15175

O-ring, (Kit : K12)

16

707-35-91840

Ring, Back-up, (Kit : K12)

17

07179-13126

Ring, Snap

18

01011-82400

Bolt

19

707-88-75410

Washer

20

707-36-18520

Piston

21

707-44-18250

Ring, Piston, (Kit : K12)

22

707-39-18510

Ring, Wear, (Kit : K12)

23

707-44-18920

Ring

24

07000-B5110

O-ring, (Kit : K12)

25

07001-05110

Ring, Back-up, (Kit : K12)

26

01310-01225

Screw

27

707-86-13080

Tube

28

208-63-73580

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K12)

32

707-88-28270

Bracket

33

707-88-26140

Band

34

07372-21240

Bolt

35

01643-51232

Washer

36

07283-33442

Clip, Pipe

37

01597-01009

Nut

38

01643-31032

Washer

39

707-88-28260

Bracket

40

707-88-33040

Cap

41

07371-31049

Flange, Split

42

07372-21035

Bolt

43

01643-51032

Washer
