Запчасти Komatsu PC400LC-8 ЦИЛИНДР РУКОЯТИ(№7-) ЦИЛИНДР РУКОЯТИ, ДЛЯ ПРЯМАЯ ЛОПАТА CONFIGURATION

|$0

707-01-0G370

Cylinder Assembly

1

707-13-18830

Cylinder

2

707-76-11130

Bushing

3

07145-00110

Seal, Dust, (Kit : K08)

4

707-58-12300

Rod

5

707-76-11130

Bushing

6

07145-00110

Seal, Dust, (Kit : K08)

7

707-71-60310

Plunger

8

04260-01270

Ball

9

707-71-91520

Cap

10

707-27-18930

Head, Cylinder

11

195-63-93170

Seal, Dust, (Kit : K08)

12

07179-13136

Ring, Snap

13

707-52-90980

Bushing

14

07179-13126

Ring, Snap

15

707-51-12030

Packing, Rod, (Kit : K08)

16

707-51-12640

Ring, Buffer, (Kit : K08)

17

707-35-91840

Ring, Back-up, (Kit : K08)

18

07000-15175

O-ring, (Kit : K08)

19

01011-82400

Bolt

20

707-88-75410

Washer

21

707-36-18520

Piston

22

01310-01225

Screw

23

707-44-18280

Ring, Piston, (Kit : K08)

24

707-39-18510

Ring, Wear, (Kit : K08)

25

707-44-18920

Ring

26

07001-05110

Ring, Back-up, (Kit : K08)

27

07000-15110

O-ring, (Kit : K08)

28

707-86-12810

Tube

29

707-86-12820

Tube

30

07372-21060

Bolt

31

01643-51032

Washer

32

07372-21060

Bolt

33

01643-51032

Washer

34

07000-13035

O-ring, (Kit : K08)

35

707-88-25620

Bracket

36

707-88-21880

Band

37

07372-21240

Bolt

38

01643-51232

Washer

39

07283-33442

Clip, Pipe

40

01643-31032

Washer

41

01597-01009

Nut

42

707-88-25630

Bracket

43

707-88-21930

Band

44

07372-21240

Bolt

45

01643-51232

Washer

46

707-88-33040

Cap

47

07371-31049

Flange, Split

48

07372-21035

Bolt

49

01643-51032

Washer
