Запчасти Komatsu PC400LC-7 ГИДР. БАК. (СПЕЦ-Я -40С) ГИДРАВЛИКА

1

208-60-71113

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-52434

O-RING

6

02783-10628

ELBOW

7

07002-52434

O-RING

8

02896-51018

O-RING

9

02782-10315

ELBOW

10

07002-52034

O-RING

11

02896-51009

O-RING

12

207-62-72110

UNION

13

07002-53334

O-RING

14

208-62-74510

O-RING

15

02782-10315

ELBOW

16

07002-52034

O-RING

17

02896-51009

O-RING

18

02783-10210

ELBOW

19

07002-51423

O-RING

20

02896-51008

O-RING

21

208-60-71123

ELEMENT

21

208-60-71122

ELEMENT

21

208-60-71121

ELEMENT

22

07069-25400

STRAINER

23

208-60-71320

VALVE A.

24

07069-34075

SPRING

25

208-60-71130

PLATE

26

07000-55210

O-RING

27

01010-81225

BOLT

28

01643-31232

WASHER

|$39

208-60-71310

STRAINER ASS'Y

29

208-60-71150

ROD ASS'Y

30

12R-60-11230

SPRING

31

20Y-60-21320

HOLDER

32

17M-60-59280

STRAINER

33

208-60-61340

COVER

34

07000-55180

O-RING

35

01010-81225

BOLT

36

01643-31232

WASHER

37

208-60-71190

BREATHER,(SEE FIG. Y1890-01A0)

38

208-60-51800

BREATHER ASS'Y

39

20Y-60-21410

ELEMENT

40

208-60-51810

PACKING

41

01252-30820

BOLT

42

07056-10045

STRAINER

43

04065-04718

RING

44

208-60-71250

SHEET

45

01010-81635

BOLT

46

01643-31645

WASHER

47

195-03-11570

SHIM, 1.0MM
