Запчасти Komatsu PC400LC-7 МОТОР ПОВОРОТА (/) (СПЕЦ-Я -40С) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

706-7K-01081

SWING MOTOR

|$3

706-7K-01080

SWING MOTOR ASS'Y

|$5

706-7K-03061

MOTOR SUB ASS'Y

|$6

706-7K-03060

MOTOR SUB ASS'Y

1

706-7K-41610

SHAFT

2

706-77-43890

BEARING

2

706-77-43880

BEARING

3

706-7K-41810

SPACER

4

706-77-42150

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

7

SPACER, 2.3MM

7

SPACER, 2.5MM

7

SPACER, 2.7MM

8

04064-06525

RING,SNAP

9

706-7K-41660

SEAL,OIL

10

706-7K-41920

SPACER

11

04065-07525

RING

12

706-7K-41210

BLOCK,CYLINDER

13

706-7K-41710

PLATE,VALVE

14

708-18-13230

PIN

15

706-7K-41120

SHAFT,CENTER

16

706-77-42130

RING,CENTER

17

706-7K-41140

SPRING

|$28

706-7K-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7K-41160

PISTON SUB ASS'Y

21

706-7K-91340

PLATE

22

706-7K-91350

DISC

23

706-7K-91111

PISTON,BRAKE

24

07000-55230

O-RING

25

706-77-91560

O-RING

26

706-7K-91360

SPRING
