Запчасти Komatsu PC400LC-7 МОТОР ХОДА (/) (СПЕЦ-Я -40С)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC400LC-7 - МОТОР ХОДА (/) (СПЕЦ-Я -40С)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
6
6
7
8
8
9
9
10
11
12
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
38
39
39
39
40
41
41
42
42
43
43
1
2
3
4
5
6
6
6
7
8
8
9
9
10
11
12
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
38
39
39
39
40
41
41
42
42
43
43

Артикул

Название

Примечание

Количество

|$1

706-8L-01030

MOTOR ASS'Y

1

706-8L-41130

CASE,MOTOR

|$4

706-8L-00030

END COVER SUB ASS'Y

2

COVER,END

3

PLATE ASS'Y,VALVE

4

BLOCK,CYLINDER

5

SPOOL

6

PLUG

7

708-8K-15190

PIN,DOWEL

8

706-77-72170

PLUG

9

07002-52434

O-RING

10

20B-27-11210

BLEEDER

11

706-8L-51030

PISTON

12

706-8L-51040

PIN

13

706-87-51120

SCREW

14

706-7G-71710

VALVE

15

706-75-74550

SPRING

16

706-75-74850

PLUG

17

07002-53334

O-RING

18

706-8L-71510

PISTON

19

706-78-71280

SPRING

20

706-78-71230

PLUG

21

07002-53634

O-RING

|$25

706-8L-00210

SLEEVE ASS'Y

22

706-88-50250

SLEEVE

23

07002-55234

O-RING

24

07000-53035

O-RING

25

706-88-50310

RING,BACK-UP

26

07000-53038

O-RING

27

706-88-50320

RING,BACK-UP

28

706-8E-14170

SPRING

29

706-8L-50210

SPOOL

30

706-88-50160

PLUG

31

07002-53034

O-RING

32

706-77-71670

PLUG

33

07002-53034

O-RING

34

706-86-53410

VALVE

35

708-8E-16160

PLUG

36

07002-51023

O-RING

37

708-8E-16180

VALVE

38

708-8E-16160

PLUG

39

07002-51023

O-RING

40

706-78-71430

SPOOL

41

706-78-71440

SPRING

42

706-78-71260

PLUG

43

07002-52034

O-RING

|$1

706-8L-01030

MOTOR ASS'Y

1

706-8L-41130

CASE,MOTOR

|$4

706-8L-00030

END COVER SUB ASS'Y

2

COVER,END

3

PLATE ASS'Y,VALVE

4

BLOCK,CYLINDER

5

SPOOL

6

PLUG

7

708-8K-15190

PIN,DOWEL

8

706-77-72170

PLUG

9

07002-52434

O-RING

10

20B-27-11210

BLEEDER

11

706-8L-51030

PISTON

12

706-8L-51040

PIN

13

706-87-51120

SCREW

14

706-7G-71710

VALVE

15

706-75-74550

SPRING

16

706-75-74850

PLUG

17

07002-53334

O-RING

18

706-8L-71510

PISTON

19

706-78-71280

SPRING

20

706-78-71230

PLUG

21

07002-53634

O-RING

|$25

706-8L-00210

SLEEVE ASS'Y

22

706-88-50250

SLEEVE

23

07002-55234

O-RING

24

07000-53035

O-RING

25

706-88-50310

RING,BACK-UP

26

07000-53038

O-RING

27

706-88-50320

RING,BACK-UP

28

706-8E-14170

SPRING

29

706-8L-50210

SPOOL

30

706-88-50160

PLUG

31

07002-53034

O-RING

32

706-77-71670

PLUG

33

07002-53034

O-RING

34

706-86-53410

VALVE

35

708-8E-16160

PLUG

36

07002-51023

O-RING

37

708-8E-16180

VALVE

38

708-8E-16160

PLUG

39

07002-51023

O-RING

40

706-78-71430

SPOOL

41

706-78-71440

SPRING

42

706-78-71260

PLUG

43

07002-52034

O-RING

Выбрано товаров: 92
