Запчасти Komatsu PC400LC-7 НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.) (СПЕЦ-Я -40С)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP111

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

707-01-XP110

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XP121

CYLINDER GROUP,R.H. (FINAL COATING)

G-2

707-01-XP120

CYLINDER GROUP,R.H. (FINAL COATING)

|$9

707-01-0K101

CYLINDER ASS'Y

|$10

707-01-0K100

CYLINDER ASS'Y

1

707-13-13820

CYLINDER

2

707-76-80010

BUSHING

3

07145-10080

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-90E80

ROD,PISTON

6

205-63-65271

BUSHING

7

07145-10080

SEAL,DUST (KIT)

8

707-27-13650

HEAD,CYLINDER

9

707-52-90681

BUSHING

10

707-51-90730

U-PACKING,ROD (KIT)

11

707-51-90640

RING,BUFFER (KIT)

12

707-75-90110

RING,SNAP

13

707-56-90740

SEAL,DUST (KIT)

14

707-56-90820

SEAL,DUST (KIT)

14

707-56-90651

SEAL,DUST (KIT)

15

707-88-03921

RING

16

707-88-05510

COLLAR

17

707-88-05520

PLATE

18

07000-55120

O-RING (KIT)

19

707-35-91320

RING,BACK-UP (KIT)

20

01010-81695

BOLT

21

01011-81600

BOLT

22

01643-51645

WASHER

23

707-36-13780

PISTON

24

707-44-13180

RING,PISTON (KIT)

25

707-39-13150

RING,WEAR (KIT)

26

707-44-13911

RING

27

07000-55080

O-RING (KIT)

28

707-35-90940

RING,BACK-UP (KIT)

29

01310-01216

SCREW

30

707-86-67280

TUBE,L.H.

30

707-86-67290

TUBE,R.H.

31

208-63-94380

TUBE,L.H.

31

208-63-94480

TUBE,R.H.

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07372-21045

BOLT

35

01643-51032

WASHER

36

07000-53030

O-RING (KIT)

37

707-88-25820

BRACKET

38

707-88-87280

BRACKET

39

707-88-87270

BAND

40

07372-21035

BOLT

41

01643-51032

WASHER

42

07282-12793

CLAMP

43

01010-81020

BOLT

44

01643-31032

WASHER

45

707-88-33030

CAP

46

07371-30640

FLANGE,SPLIT

47

07372-21035

BOLT

48

01643-51032

WASHER

|$66

707-99-47821

SERVICE KIT

|$67

707-99-47820

SERVICE KIT
