Запчасти Komatsu PC400LC-7-M1 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT330

BOOM CYLINDER ASS'Y,L.H. (FINAL COATING)

G-1

707-01-XG350

BOOM CYLINDER GROUP,L.H.

G-2

707-01-XT340

BOOM CYLINDER ASS'Y,R.H. (FINAL COATING)

G-2

707-01-XG360

BOOM CYLINDER GROUP,R.H.

|1

707-01-0G350

CYLINDER ASS'Y

1

707-13-16960

CYLINDER

2

707-76-10270

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-11620

ROD

6

707-76-10130

BUSHING

7

07145-00100

SEAL,DUST (KIT)

8

707-71-71610

COLLAR

9

707-35-91640

RING,BACK-UP (KIT)

10

07000-15150

O-RING (KIT)

11

707-71-61140

PLUNGER

12

707-27-16580

HEAD

13

198-63-94170

SEAL,DUST (KIT)

14

07179-13126

RING,SNAP

15

707-52-90850

BUSHING

16

707-75-11040

RING,SNAP

17

707-51-11030

PACKING,ROD (KIT)

18

707-51-11640

RING,BUFFER (KIT)

19

707-35-91640

RING,BACK-UP (KIT)

20

07000-15150

O-RING (KIT)

21

01010-82085

BOLT

22

707-88-75310

WASHER

23

707-36-16580

PISTON

24

01310-01216

SCREW

25

707-44-16180

RING,PISTON (KIT)

26

707-39-16120

RING,WEAR (KIT)

27

707-44-16910

RING

28

07001-05100

RING,BACK-UP (KIT)

29

07000-15100

O-RING (KIT)

30

707-86-12790

TUBE,L.H.

|30

707-86-12800

TUBE,R.H.

31

208-63-53181

TUBE,L.H.

|31

208-63-53281

TUBE,R.H.

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING (KIT)

35

707-88-25370

BRACKET,L.H.

|35

707-88-25380

BRACKET,R.H.

36

707-88-21660

BAND

37

07372-21240

BOLT

38

01643-51232

WASHER

39

07283-33442

CLIP

40

01643-31032

WASHER

41

01597-01009

NUT

42

01010-81025

BOLT

43

01643-31032

WASHER

44

707-88-33040

CAP

45

07371-31049

FLANGE,SPLIT

46

07372-21035

BOLT

47

01643-51032

WASHER

|K

707-99-67090

SERVICE KIT
