Запчасти Komatsu PC400LC-6Z ГЛАВН. КЛАПАН (- DEG. СПЕЦ-Я.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-21-09220

PILOT VALVE

|$3

702-21-55300

VALVE ASS'Y,RELIEF

1

SLEEVE

2

COLLAR

3

FILTER

4

POPPET

5

SPRING

6

SCREW

7

NUT

8

O-RING

9

702-21-55820

O-RING

10

O-RING

11

07002-51623

O-RING

12

BLOCK

13

702-21-55310

VALVE

14

702-21-55460

SPRING

15

702-21-55830

O-RING

16

702-21-55840

O-RING

17

702-21-55850

O-RING

18

702-21-53120

FILTER

19

07000-51009

O-RING

20

702-21-55410

PLATE

21

01252-60820

BOLT

22

01643-50823

WASHER

23

702-21-55860

O-RING

24

BLOCK

25

SPOOL

26

702-21-55640

SPRING

27

702-21-55620

PLUG

28

07002-51423

O-RING

29

702-21-55710

SEAT

30

702-21-55720

SPRING

31

04260-00793

BALL

32

07000-51009

O-RING

33

PLUG

34

702-21-55670

ORIFICE

35

702-21-55470

ORIFICE

36

01252-60520

BOLT

37

702-21-55480

FRANGE

38

07000-52020

O-RING

39

01252-61025

BOLT
