Запчасти Komatsu PC400LC-6Z БЛОК КОНДИЦИОНЕРА(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC400LC-6Z - БЛОК КОНДИЦИОНЕРА(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5A
6
6A
7
8
9
10
10
11
12
13
14
14
15
16
17
18
19
20
21
21
22
23
24
25
26
27
28
29
30
31
31
32
33
34
35
35
36
37
37
38
39
39
40
41
42
43
44
45
45
45
45
45
45
45
45
45
45
45
45
45
46
46
47
47
48
48
49
49
50
50
50
51

Артикул

Название

Примечание

Количество

|$0

201-979-7673

UNIT ASS'Y

|$1

201-979-7672

UNIT ASS'Y

1

TW534135-1200

CASE

2

TW534135-1300

CASE

3

TW534135-1020

CASE ASS'Y

4

TW534135-1120

CASE ASS'Y

5

TW534160-2720

SCROLL ASS'Y

5A

TW534160-2121

SCROLL ASS'Y

6

TW503700-2532

EVAPORATOR ASS'Y

6

TW503700-2531

EVAPORATOR ASS'Y

6A

TW582531-0200

SWITCH,PRESSURE

6B

TW503714-0830

EXPANSION VALVE,PRESSURE

7

TW502700-1721

HEATER CORE ASS'Y

7A

TW521430-0020

STEM ASS'Y

8

203-979-6840

FILTER

9

203-979-6850

FILTER

10

TW535011-0920

COVER

11

203-979-6860

RESISTOR

12

TW582550-9600

THERMOSTAT

13

TW502752-2380

MOTOR ACTUATOR

14

TW502752-2320

MOTOR ACTUATOR

15

TW534270-2920

DOOR

16

TW534270-3020

DOOR

17

TW534270-3120

DOOR

18

TW534270-3221

DOOR

19

TW534470-3400

LEVER

20

TW534470-3500

LEVER

21

TW534470-2200

LEVER

22

TW534470-3621

LEVER

22

TW534470-3620

LEVER

23

TW534480-1400

ROD

24

TW534480-1600

ROD

25

TW534480-1700

ROD

26

TW534480-1500

ROD

27

TW503716-1900

FAN MOTOR ASS'Y

27A

TW523220-1800

FAN

27B

TW029600-8040

RING, SNAP

27C

TW592050-0500

RING, SNAP

28

TW534510-4600

AIR HOSE

29

TW592405-1600

ISOLATOR

30

TW592039-5900

WASHER

31

TW592055-0900

CLIP

32

TW592417-0300

CLIP

33

TW580530-6800

CLIP

34

TW580530-6901

CLIP

34

TW580530-6900

CLIP

35

TW580521-6800

CLIP

36

TW580520-1300

CLIP

37

TW592024-3100

CLIP

38

TW582592-5720

RELAY ASS'Y

39

TW534103-0201

BRACKET

40

TW534103-2721

BRACKET

41

TW534103-2121

BRACKET

42

TW534186-4600

LINING

43

TW534186-4500

LINING

44

TW012554-0840

SCREW

45

TW012515-1640

TAPPING SCREW

46

TW012514-1640

TAPPING SCREW

47

TW580140-0300

TAPPING SCREW

48

TW580150-5200

TAPPING SCREW

49

TW536019-9723

WIRING HARNESS

50

TW592022-3600

TAPPING SCREW

51

TW534103-2920

BRACKET

Выбрано товаров: 63
