Запчасти Komatsu PC400LC-6Z PIPE LOOPER (ПРИВОД КОРПУС)(№9-) РАЗНОЕ

1

887-0094-930

MOTOR ASS'Y

2

207-26-71240

RING

|$6

208-27-00210

FLOATING SEAL ASS'Y

3

RING

4

O-RING

5

208-871-5120

CASE

6

154-09-71140

BEARING

7

07000-15415

O-RING

8

208-871-5111

HUB

9

07044-12412

PLUG

10

07002-12434

O-RING

11

04065-04718

RING

12

208-871-5180

PLATE

13

20Y-27-21331

NUT

14

20Y-27-21341

LOCK

15

01010-81020

BOLT

16

208-871-5130

CARRIER

17

208-26-71140

GEAR

18

207-27-61230

BEARING

19

20Y-27-21250

WASHER

20

207-27-61250

PIN

21

20Y-27-21290

PIN

22

208-26-71230

PLATE

23

205-32-51211

BOLT

24

208-26-71150

GEAR

25

01010-81645

BOLT

26

01643-31645

WASHER

27

208-26-71130

GEAR

28

208-26-71241

PLATE

29

208-26-71170

CARRIER

30

207-26-71520

GEAR

31

22U-26-21470

BEARING

32

22U-26-21240

WASHER

33

207-26-71210

PIN

34

04064-04018

RING

35

208-26-71210

HOLDER

36

04260-01270

BALL

37

207-26-71510

GEAR

38

207-26-71261

PLATE

39

01010-81240

BOLT

40

01643-31232

WASHER

41

208-871-5150

CAP

42

208-871-5140

TUBE

43

07238-10630

CONNECTOR

44

07286-01065

HOSE

44

07286-01070

HOSE

45

07285-00130

CLIP

45

07281-00167

CLAMP

46

208-871-5160

BRACKET

47

208-871-5170

JOINT

48

07002-11223

O-RING

49

07283-32738

CLIP

50

01597-01009

NUT

51

01643-31032

WASHER

52

01010-81030

BOLT

53

01643-31032

WASHER

54

01011-83015

BOLT

55

01643-33080

WASHER

56

01011-82460

BOLT

57

01643-32460

WASHER
