Запчасти Komatsu PC400LC-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/) (ДЛЯ ПОГРУЗ.) (С ПРЕДОТВРАЩ. СМЕЩЕНИЯ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-19600

CONTROL VALVE

|1

723-48-19303

CONTROL VALVE

|1

723-48-19302

CONTROL VALVE

|1

723-48-19301

CONTROL VALVE

|1

723-48-19300

CONTROL VALVE

|1

723-48-17300

CONTROL VALVE

|1

BODY SUB ASS'Y

1

723-46-41110

VALVE

|2

723-46-45100

VALVE ASS'Y

2

SLEEVE

3

PISTON SUB ASS'Y

4

SPRING

5

SEAL

6

700-93-11320

O-RING

7

723-46-41950

RING

8

07002-13634

O-RING

9

01252-60845

BOLT

10

01643-50823

WASHER

|11

723-40-66300

VALVE ASS'Y

11

CASE

12

SEAT

13

SEAT

14

BALL

15

PLUG

|16

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

16

SLEEVE

17

SLEEVE

18

POPPET

19

PISTON

20

PLUG

21

POPPET

22

SCREW

23

SPRING

24

SPRING

25

SPRING

26

SEAL

27

SEAL

28

709-25-11390

O-RING

29

O-RING

30

O-RING

31

NUT

|32

709-70-74203

VALVE ASS'Y,SUCTION AND SAFETY

32

SLEEVE

33

SLEEVE

34

POPPET

35

PISTON

36

PLUG

37

POPPET

38

SCREW

39

SPRING

40

SPRING

41

SPRING

42

SEAL

43

SEAL

44

709-25-11390

O-RING

45

O-RING

46

O-RING

47

NUT
