Запчасти Komatsu PC400LC-6Z МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

706-77-01380

MOTOR ASS'Y

|$3

706-77-01311

MOTOR ASS'Y

|$7

706-77-03130

MOTOR SUB ASS'Y

1

706-77-43210

CASE,MOTOR

2

706-77-72610

HOUSING

3

706-75-42830

PIN,DOWEL

4

706-77-72170

PLUG

5

07002-12434

O-RING

6

706-73-71450

PLUG

7

07002-11423

O-RING

8

706-7G-40010

BEARING

9

706-7E-11440

O-RING

10

706-77-43180

BOLT

11

706-77-43860

SHAFT

12

706-77-43880

BEARING

13

706-77-42890

BEARING

14

706-77-42051

SPRING

15

706-77-42041

SEAT

16

706-77-05010

SPACER KIT

16

SPACER, 2.3MM

16

SPACER, 2.5MM

16

SPACER, 2.7MM

17

04064-06525

RING,SNAP

18

706-77-43950

SEAL,OIL

19

706-77-43060

COVER

20

07000-02125

O-RING

21

04071-00130

RING,SNAP

22

706-77-43191

BLOCK,CYLINDER

23

706-77-43840

PLATE,VALVE

24

708-18-13230

PIN

25

706-77-43080

SHAFT,CENTER

26

706-77-42130

RING,CENTER

27

706-77-42110

SPRING

|$38

706-77-05050

RETAINER KIT

28

RETAINER

29

SCREW

30

706-77-42160

PISTON SUB ASS'Y

31

706-77-91540

PLATE

32

706-77-91550

DISC

33

706-77-91580

PISTON,BRAKE

34

07000-15180

O-RING

35

708-8H-15220

O-RING

36

706-77-91510

SPRING
