Запчасти Komatsu PC400LC-6LM FIG. A-AG ВОЗДУХООЧИСТИТЕЛЬ ДВИГАТЕЛЬ

|$0

6151-81-7700

AIR CLEANER ASSEMBLY

1

6692-81-7311

BODY

|$2

6125-81-7032

ELEMENT ASSEMBLY

2

NSS

ELEMENT, INNER

3

600-181-9671

NUT

4

600-181-7511

WASHER

|$6

600-181-4300

ELEMENT ASSEMBLY, OUTER

5

NSS

ELEMENT, OUTER

6

600-181-1990

NUT, WING

7

600-181-4591

WASHER, SEAL

8

04064-01510

RING, SNAP

9

6710-82-7130

BAFFLE

10

6710-82-7121

CUP

11

600-181-1590

VALVE

12

6127-81-7190

ORING

13

600-181-1490

CLAMP

14

6127-81-4823

GASKET

15

01580-11008

NUT

16

01640-21016

WASHER

17

6691-13-4610

BAND ASSEMBLY

|$20

6691-21-6550

PIN

|$21

6691-21-6560

PIN, WITH THREAD

18

6643-11-4641

BOLT

19

6152-12-4560

BRACKET

20

01010-51660

BOLT

21

01010-81025

BOLT

22

6152-12-4260

CONNECTOR

23

6151-12-4470

HOSE

24

07289-00105

CLAMP

25

6152-12-4650

BRACKET

26

01010-81035

BOLT

27

01010-E1040

BOLT

28

6631-11-5630

SPACER

29

01640-21016

WASHER

30

6152-12-4680

PLATE

31

01010-E1035

BOLT

32

6631-11-5630

SPACER
